"""Common utility functions for datamodel alignment."""
from __future__ import annotations
import functools
import logging
import re
from typing import TYPE_CHECKING, Tuple
import warnings
if TYPE_CHECKING:
from collections.abc import Callable, Sequence
import astropy
import gwcs
from gwcs import coordinate_frames as cf
from gwcs import FITSImagingWCSTransform
import numpy as np
from astropy import wcs as fitswcs
from astropy import coordinates as coord
from astropy.modeling import models as astmodels
from astropy import units as u
log = logging.getLogger(__name__)
log.setLevel(logging.DEBUG)
__all__ = [
"compute_scale",
"compute_fiducial",
"calc_rotation_matrix",
"compute_s_region_imaging",
"compute_s_region_keyword",
"sregion_to_footprint",
"wcs_from_footprints",
"wcs_from_sregions",
"wcs_bbox_from_shape",
"reproject",
]
def _calculate_fiducial_from_spatial_footprint(
spatial_footprint: np.ndarray,
) -> tuple:
"""
Calculates the fiducial coordinates from a given spatial footprint.
Parameters
----------
spatial_footprint : np.ndarray
An Nx2 array containing the world coordinates of the WCS footprint's
bounding box, where N is the number of bounding box positions.
Returns
-------
lon_fiducial, lat_fiducial : np.ndarray, np.ndarray
The world coordinates of the fiducial point in the output coordinate frame.
"""
lon, lat = spatial_footprint.T
lon, lat = np.deg2rad(lon), np.deg2rad(lat)
x = np.cos(lat) * np.cos(lon)
y = np.cos(lat) * np.sin(lon)
z = np.sin(lat)
x_mid = (np.max(x) + np.min(x)) / 2.0
y_mid = (np.max(y) + np.min(y)) / 2.0
z_mid = (np.max(z) + np.min(z)) / 2.0
lon_fiducial = np.rad2deg(np.arctan2(y_mid, x_mid)) % 360.0
lat_fiducial = np.rad2deg(np.arctan2(z_mid, np.sqrt(x_mid**2 + y_mid**2)))
return lon_fiducial, lat_fiducial
def _calculate_fiducial(footprints: list[np.ndarray],
crval: Sequence | None = None) -> tuple:
"""
Calculates the coordinates of the fiducial point and, if necessary, updates it with
the values in CRVAL (the update is applied to spatial axes only).
Parameters
----------
footprints : list
A list of numpy arrays each of shape (N, 2) containing the
(RA, Dec) vertices demarcating the footprint of the input WCSs.
crval : list, optional
A reference world coordinate associated with the reference pixel. If not `None`,
then the fiducial coordinates of the spatial axes will be updated with the
values from ``crval``.
Returns
-------
fiducial : tuple
A tuple containing the world coordinate of the fiducial point.
"""
if crval is not None:
return tuple(crval)
return _compute_fiducial_from_footprints(footprints)
def _validate_wcs_list(wcs_list: list[gwcs.wcs.WCS]) -> bool:
"""
Validates wcs_list.
Parameters
----------
wcs_list : list
A list of WCS objects.
Returns
-------
bool or Exception
If wcs_list is valid, returns True. Otherwise, it will raise an error.
Raises
------
ValueError
Raised whenever wcs_list is not an iterable.
TypeError
Raised whenever wcs_list is empty or any of its content is not an
instance of WCS.
"""
if not np.iterable(wcs_list):
msg = "Expected 'wcs_list' to be an iterable of WCS objects."
raise ValueError(msg)
if len(wcs_list):
if not all(isinstance(w, gwcs.WCS) for w in wcs_list):
msg = "All items in 'wcs_list' are to be instances of gwcs.wcs.WCS."
raise TypeError(msg)
else:
msg = "'wcs_list' should not be empty."
raise TypeError(msg)
return True
[docs]
def compute_scale(
wcs: gwcs.wcs.WCS,
fiducial: tuple | np.ndarray,
disp_axis: int | None = None,
pscale_ratio: float | None = None,
) -> float:
"""Compute the scale at the fiducial point on the detector..
Parameters
----------
wcs : ~gwcs.wcs.WCS
Reference WCS object from which to compute a scaling factor.
fiducial : tuple
Input fiducial of (RA, DEC) or (RA, DEC, Wavelength) used in calculating
reference points.
disp_axis : int, None, optional
Dispersion axis integer. Assumes the same convention as
``wcsinfo.dispersion_direction``
pscale_ratio : int, None, optional
Ratio of output pixel scale to input pixel scale.
Returns
-------
scale : float
Scaling factor for x and y or cross-dispersion direction.
"""
spectral = "SPECTRAL" in wcs.output_frame.axes_type
if spectral and disp_axis is None:
msg = "If input WCS is spectral, a disp_axis must be given"
raise ValueError(msg)
crpix = np.array(wcs.invert(*fiducial, with_bounding_box=False))
delta = np.zeros_like(crpix)
spatial_idx = np.where(np.array(wcs.output_frame.axes_type) == "SPATIAL")[0]
delta[spatial_idx[0]] = 1
crpix_with_offsets = np.vstack((crpix, crpix + delta, crpix + np.roll(delta, 1))).T
crval_with_offsets = wcs(*crpix_with_offsets, with_bounding_box=False)
coords = coord.SkyCoord(
ra=crval_with_offsets[spatial_idx[0]],
dec=crval_with_offsets[spatial_idx[1]],
unit="deg",
)
xscale = np.abs(coords[0].separation(coords[1]).value)
yscale = np.abs(coords[0].separation(coords[2]).value)
if pscale_ratio is not None:
xscale *= pscale_ratio
yscale *= pscale_ratio
if spectral:
# Assuming scale doesn't change with wavelength
# Assuming disp_axis is consistent with DataModel.meta.wcsinfo.dispersion.direction
return float(yscale) if disp_axis == 1 else float(xscale)
return float(np.sqrt(xscale * yscale))
[docs]
def compute_fiducial(wcslist: list,
bounding_box: Sequence | None = None) -> np.ndarray:
"""
Calculates the world coordinates of the fiducial point of a list of WCS objects.
For a celestial footprint this is the center. For a spectral footprint, it is the
beginning of its range.
Parameters
----------
wcslist : list
A list containing all the WCS objects for which the fiducial is to be
calculated.
bounding_box : tuple, list, None, optional
The bounding box over which the WCS is valid. It can be a either tuple of tuples
or a list of lists of size 2 where each element represents a range of
(low, high) values. The bounding_box is in the order of the axes, axes_order.
For two inputs and axes_order(0, 1) the bounding box can be either
((xlow, xhigh), (ylow, yhigh)) or [[xlow, xhigh], [ylow, yhigh]].
Returns
-------
fiducial : np.ndarray
A two-elements array containing the world coordinates of the fiducial point
in the combined output coordinate frame.
Notes
-----
This function assumes all WCSs have the same output coordinate frame.
"""
axes_types = wcslist[0].output_frame.axes_type
spatial_axes = np.array(axes_types) == "SPATIAL"
spectral_axes = np.array(axes_types) == "SPECTRAL"
footprints = np.hstack([w.footprint(bounding_box=bounding_box).T for w in wcslist])
spatial_footprint = footprints[spatial_axes]
spectral_footprint = footprints[spectral_axes]
fiducial = np.empty(len(axes_types))
if spatial_footprint.any():
fiducial[spatial_axes] = _calculate_fiducial_from_spatial_footprint(spatial_footprint.T)
if spectral_footprint.any():
fiducial[spectral_axes] = spectral_footprint.min()
return fiducial
def _compute_fiducial_from_footprints(footprints: list[np.ndarray]) -> tuple:
"""
Calculates the world coordinates of the fiducial point of a list of WCS objects.
For a celestial footprint this is the center. For a spectral footprint, it is the
beginning of its range.
Parameters
----------
footprints : list
A list of numpy arrays each of shape (N, 2) containing the
(RA, Dec) vertices demarcating the footprint of the input WCSs.
bounding_box : tuple, list, None
The bounding box over which the WCS is valid. It can be a either tuple of tuples
or a list of lists of size 2 where each element represents a range of
(low, high) values. The bounding_box is in the order of the axes, axes_order.
For two inputs and axes_order(0, 1) the bounding box can be either
((xlow, xhigh), (ylow, yhigh)) or [[xlow, xhigh], [ylow, yhigh]].
Returns
-------
fiducial : tuple
A tuple containing the world coordinates of the fiducial point
in the combined output coordinate frame.
Notes
-----
This function assumes all WCSs have the same output coordinate frame.
"""
spatial_footprint = np.vstack(footprints)
return _calculate_fiducial_from_spatial_footprint(spatial_footprint)
[docs]
def calc_rotation_matrix(roll_ref: float, v3i_yangle: float, vparity: int = 1) -> list[float]:
r"""Calculate the rotation matrix.
Parameters
----------
roll_ref : float
Telescope roll angle of V3 North over East at the ref. point in radians
v3i_yangle : float
The angle between ideal Y-axis and V3 in radians.
vparity : int
The x-axis parity, usually taken from the JWST SIAF parameter VIdlParity.
Value should be "1" or "-1".
Returns
-------
matrix: list
A list containing the rotation matrix elements in column order.
Notes
-----
The rotation matrix is
.. math::
PC = \\begin{bmatrix}
pc_{1,1} & pc_{2,1} \\\\
pc_{1,2} & pc_{2,2}
\\end{bmatrix}
"""
if vparity not in (1, -1):
msg = f"vparity should be 1 or -1. Input was: {vparity}"
raise ValueError(msg)
rel_angle = roll_ref - (vparity * v3i_yangle)
pc1_1 = vparity * np.cos(rel_angle)
pc1_2 = np.sin(rel_angle)
pc2_1 = vparity * -np.sin(rel_angle)
pc2_2 = np.cos(rel_angle)
return [pc1_1, pc1_2, pc2_1, pc2_2]
def _compute_bounding_box_with_offsets(
footprints: list[np.ndarray],
transform: astmodels.Model,
fiducial: Sequence,
crpix: Sequence | None,
shape: Sequence | None
) -> Tuple[tuple, tuple, tuple]:
"""
Calculates axis minimum values and bounding box.
Calculates the offsets to the transform.
Parameters
----------
footprints : list
A list of numpy arrays each of shape (N, 2) containing the
(RA, Dec) vertices demarcating the footprint of the input WCSs.
transform : ~astmodel.Model
A transform including scaling and rotation.
fiducial : tuple
A tuple containing the world coordinates of the fiducial point.
crpix : list or tuple, None, optional
0-indexed pixel coordinates of the reference pixel.
shape : tuple, None, optional
Shape (using `numpy.ndarray` convention) of the image array associated
with the ``ref_wcs``.
Returns
-------
tuple
A tuple containing the bounding box region in the format
((x0_lower, x0_upper), (x1_lower, x1_upper), ...).
tuple
Shape of the image. When ``shape`` argument is `None`, shape is
determined from the upper limit of the computed bounding box, otherwise
input value of ``shape`` is returned.
tuple
A tuple with the offsets of the reference pixel to be added to the WCS's transform.
"""
domain_bounds = np.hstack([transform.inverse(*f.T) for f in footprints])
domain_min = np.min(domain_bounds, axis=1)
domain_max = np.max(domain_bounds, axis=1)
native_crpix = transform.inverse(*fiducial)
if crpix is None:
# shift the coordinates by domain_min so that all input footprints
# will project to positive coordinates in the offsetted ref_wcs
offsets = tuple(ncrp - dmin for ncrp, dmin in zip(native_crpix,
domain_min))
else:
# assume 0-based CRPIX and require that fiducial would map to the user
# defined crpix value:
offsets = tuple(
crp - ncrp for ncrp, crp in zip(native_crpix, crpix)
)
# Also offset domain limits:
domain_min += offsets
domain_max += offsets
if shape is None:
shape = tuple(int(dmax + 0.5) for dmax in domain_max[::-1])
bounding_box = tuple(
(-0.5, s - 0.5) for s in shape[::-1]
)
else:
# trim upper bounding box limits
shape = tuple(shape)
bounding_box = tuple(
(max(0, int(dmin + 0.5)) - 0.5, min(int(dmax + 0.5), sz) - 0.5)
for dmin, dmax, sz in zip(domain_min, domain_max, shape[::-1])
)
return bounding_box, shape, offsets
[docs]
def wcs_from_sregions(
footprints: list[np.ndarray] | list[str],
ref_wcs: gwcs.wcs.WCS,
ref_wcsinfo: dict,
transform: astropy.modeling.models.Model | None = None,
pscale_ratio: float | None = None,
pscale: float | None = None,
rotation: float | None = None,
shape: Sequence | None = None,
crpix: Sequence | None = None,
crval: Sequence | None = None,
) -> gwcs.wcs.WCS:
"""
Create a WCS from a list of input s_regions or footprints.
A fiducial point in the output coordinate frame is created from the
footprints of all WCS objects. For a spatial frame this is the center
of the union of the footprints. For a spectral frame the fiducial is in
the beginning of the footprint range.
If ``refmodel`` is None, the first WCS object in the list is considered
a reference. The output coordinate frame and projection (for celestial frames)
is taken from ``refmodel``.
If ``transform`` is not supplied, a compound transform is created using
CDELTs and PC.
If ``bounding_box`` is not supplied, the `bounding_box` of the new WCS is computed
from `bounding_box` of all input WCSs.
Parameters
----------
footprints : list of np.ndarray or list of str
If list elements are numpy arrays, each should have shape (N, 2) and contain
(RA, Dec) vertices demarcating the footprint of the input WCSs.
If list elements are strings, each should be the S_REGION header keyword
containing (RA, Dec) vertices demarcating the footprint of the input WCSs.
ref_wcs : ~gwcs.wcs.WCS
A WCS used as reference for the creation of the output
coordinate frame, projection, and scaling and rotation transforms.
ref_wcsinfo : dict
A dictionary containing the WCS FITS keywords and corresponding values.
transform : ~astropy.modeling.Model, None, optional
A transform, the inverse of which is used to transform the `fiducial` to detecor coordinates.
If not supplied `Scaling | Rotation` is computed from ``refmodel``.
pscale_ratio : float, None, optional
Ratio of output pixel scale to input pixel scale. Ignored when either
``transform`` or ``pscale`` are provided.
pscale : float, None, optional
Absolute pixel scale in degrees. When provided, overrides
``pscale_ratio``. Ignored when ``transform`` is provided.
rotation : float, None, optional
Position angle of output image's Y-axis relative to North.
A value of 0.0 would orient the final output image to be North up.
The default of `None` specifies that the images will not be rotated,
but will instead be resampled in the default orientation for the camera
with the x and y axes of the resampled image corresponding
approximately to the detector axes. Ignored when ``transform`` is
provided.
shape : tuple of int, None, optional
Shape of the image (data array) using ``np.ndarray`` convention
(``ny`` first and ``nx`` second). This value will be assigned to
``pixel_shape`` and ``array_shape`` properties of the returned
WCS object.
crpix : tuple of float, None, optional
Position of the reference pixel in the image array. If ``crpix`` is not
specified, it will be set to the center of the bounding box of the
returned WCS object.
crval : tuple of float, None, optional
Right ascension and declination of the reference pixel. Automatically
computed if not provided.
Returns
-------
wcs_new : ~gwcs.wcs.WCS
The WCS object corresponding to the combined input footprints.
"""
footprints = [sregion_to_footprint(s_region)
if isinstance(s_region, str) else s_region
for s_region in footprints]
fiducial = _calculate_fiducial(footprints, crval=crval)
crval = fiducial
v3yangle = np.deg2rad(ref_wcsinfo["v3yangle"])
vparity = ref_wcsinfo["vparity"]
if rotation is None:
roll_ref = np.deg2rad(ref_wcsinfo["roll_ref"])
else:
roll_ref = np.deg2rad(rotation) + (vparity * v3yangle)
pc = np.reshape(calc_rotation_matrix(roll_ref, v3yangle, vparity=vparity), (2, 2))
if not pscale:
pscale = compute_scale(ref_wcs, (ref_wcsinfo['ra_ref'], ref_wcsinfo['dec_ref']), pscale_ratio=pscale_ratio)
projection = astmodels.Pix2Sky_TAN()
cdelt = [pscale, pscale]
if transform is None:
transform = (
astmodels.AffineTransformation2D(matrix=pc)
| astmodels.Scale(pscale) & astmodels.Scale(pscale)
| projection
| astmodels.RotateNative2Celestial(crval[0], crval[1], 180)
)
bounding_box, shape, offsets = _compute_bounding_box_with_offsets(
footprints,
transform,
fiducial=crval,
crpix=crpix,
shape=shape
)
if any(d < 2 for d in shape):
raise ValueError(
"Computed shape for the output image using provided "
"WCS parameters is too small.",bounding_box, shape, offsets
)
fwcs = FITSImagingWCSTransform(projection, crpix=offsets, crval=crval,
cdelt=cdelt, pc=pc)
input_frame = ref_wcs.input_frame
output_frame = ref_wcs.output_frame
new_wcs = gwcs.WCS([gwcs.Step(input_frame, fwcs),
gwcs.Step(output_frame, None)])
new_wcs.bounding_box = bounding_box
new_wcs.pixel_shape = shape[::-1]
return new_wcs
[docs]
def compute_s_region_imaging(wcs: gwcs.wcs.WCS,
shape: Sequence | None = None,
center: bool = True) -> str | None:
"""
Update the ``S_REGION`` keyword using the WCS footprint.
Parameters
----------
wcs : ~gwcs.wcs.WCS
The WCS object.
shape : tuple, None, optional
Shape of input model data array. Used to compute the bounding box if not
provided in the WCS object, and required in that case. The default is None.
center : bool, None, optional
Whether or not to use the center of the pixel as reference for the
coordinates, by default True
Returns
-------
s_region : str
String containing the S_REGION object.
"""
bbox = wcs.bounding_box
if shape is None and bbox is None:
msg = "If wcs.bounding_box is not specified, shape must be provided."
raise ValueError(msg)
if shape is not None and bbox is None:
bbox = wcs_bbox_from_shape(shape)
wcs.bounding_box = bbox
# footprint is an array of shape (2, 4) as we
# are interested only in the footprint on the sky
### TODO: we shouldn't use center=True in the call below because we want to
### calculate the coordinates of the footprint based on the *bounding box*,
### which means we are interested in each pixel's vertice, not its center.
### By using center=True, a difference of 0.5 pixel should be accounted for
### when comparing the world coordinates of the bounding box and the footprint.
footprint = wcs.footprint(bbox, center=center, axis_type="spatial").T
# take only imaging footprint
footprint = footprint[:2, :]
# Make sure RA values are all positive
np.mod(footprint[0], 360, out=footprint[0])
footprint = footprint.T
return compute_s_region_keyword(footprint)
[docs]
def wcs_bbox_from_shape(shape: Sequence) -> tuple:
"""Create a bounding box from the shape of the data.
This is appropriate to attach to a wcs object
Parameters
----------
shape : tuple
The shape attribute from a `np.ndarray` array
Returns
-------
bbox : tuple
Bounding box in x, y order.
"""
return (-0.5, shape[-1] - 0.5), (-0.5, shape[-2] - 0.5)
[docs]
def compute_s_region_keyword(footprint: np.ndarray) -> str | None:
"""Update the S_REGION keyword.
Parameters
----------
footprint :
A 4x2 numpy array containing the coordinates of the vertices of the footprint.
Returns
-------
s_region : str
String containing the S_REGION object.
"""
s_region = "POLYGON ICRS {:.9f} {:.9f} {:.9f} {:.9f} {:.9f} {:.9f} {:.9f} {:.9f}".format(
*footprint.flatten()
)
if "nan" in s_region:
# do not update s_region if there are NaNs.
log.info("There are NaNs in s_region, S_REGION not updated.")
return None
log.info("Update S_REGION to %s", s_region)
return s_region
[docs]
def reproject(wcs1: gwcs.wcs.WCS, wcs2: gwcs.wcs.WCS) -> Callable:
"""
Given two WCSs or transforms return a function which takes pixel
coordinates in the first WCS or transform and computes them in pixel coordinates
in the second one. It performs the forward transformation of ``wcs1`` followed by the
inverse of ``wcs2``.
Parameters
----------
wcs1 : astropy.wcs.WCS or gwcs.wcs.WCS
Input WCS objects or transforms.
wcs2 : astropy.wcs.WCS or gwcs.wcs.WCS
Output WCS objects or transforms.
Returns
-------
Function to compute the transformations. It takes x, y
positions in ``wcs1`` and returns x, y positions in ``wcs2``.
"""
def _get_forward_transform_func(wcs1):
"""Get the forward transform function from the input WCS. If the wcs is a
fitswcs.WCS object all_pix2world requires three inputs, the x (str, ndarrray),
y (str, ndarray), and origin (int). The origin should be between 0, and 1
https://docs.astropy.org/en/latest/wcs/index.html#loading-wcs-information-from-a-fits-file
).
"""
if isinstance(wcs1, fitswcs.WCS):
forward_transform = wcs1.all_pix2world
elif isinstance(wcs1, gwcs.WCS):
forward_transform = wcs1.forward_transform
else:
msg = "Expected input to be astropy.wcs.WCS or gwcs.WCS object"
raise TypeError(msg)
return forward_transform
def _get_backward_transform_func(wcs2):
if isinstance(wcs2, fitswcs.WCS):
backward_transform = wcs2.all_world2pix
elif isinstance(wcs2, gwcs.WCS):
backward_transform = wcs2.backward_transform
else:
msg = "Expected input to be astropy.wcs.WCS or gwcs.WCS object"
raise TypeError(msg)
return backward_transform
def _reproject(x: float | np.ndarray, y: float | np.ndarray) -> tuple:
"""
Reprojects the input coordinates from one WCS to another.
Parameters
----------
x : float or np.ndarray
x-coordinate(s) to be reprojected.
y : float or np.ndarray
y-coordinate(s) to be reprojected.
Returns
-------
tuple
Tuple of np.ndarrays including reprojected x and y coordinates.
"""
# example inputs to resulting function (12, 13, 0) # third number is origin
# uses np.arrays for shape functionality
if not isinstance(x, (np.ndarray)):
x = np.array(x)
if not isinstance(y, (np.ndarray)):
y = np.array(y)
if x.shape != y.shape:
msg = "x and y must be the same length"
raise ValueError(msg)
sky = _get_forward_transform_func(wcs1)(x, y, 0)
# rearrange into array including flattened x and y values
flat_sky = [axis.flatten() for axis in sky]
det = np.array(_get_backward_transform_func(wcs2)(flat_sky[0], flat_sky[1], 0))
det_reshaped = [axis.reshape(x.shape) for axis in det]
return tuple(det_reshaped)
return _reproject
